Intelligent Mobile Terminal BV7237S UHF product design concept is based on robustness, multifunctional usage and convenient operation. With abundant functionality of Android operating system, PDA BV7237 UHF can quickly and effectively integrate various operational needs, including voice communications, wireless data transmission, positioning, multimedia and data acquisition, etc.
Intelligent Mobile Terminal BV7237S UHF is easy to operate. Based on Android 6.0 operating platform and adopting high-performance quad-core 1.45GHz processor, it is with high performance, first-class configuration, safety and reliability. Customized R & D for the medical industry, based on the operational environment and the specific operational requirements in medical industry, exclusively R & D customized kernel and a variety of data acquisition functions, such as one or two-dimensional bar code scanning, RFID (HF / NFC), fingerprint recognition, photography, it achieves fast and accurate reading of patient identification and information collection of wristbands, infusion bags, laboratory file barcode information and RFID information. It will improve the working efficiency of hospitals and eliminate medical errors.
It is perfect for hospitals, medical retirement institutions, nursing homes and other healthcare industries. Electronic information can be synchronized to the Hospital Information System via Wi-Fi, 4G, Bluetooth and other wireless Internet. PDA BV7237 UHF is not only conducive for hospital staffs to provide better and professional medical services, but also helps to improve the hospital management.
Quad-core 64-bit 1.45 GHz CPU design, high performance, power saving and smooth graphics display
Android 6.0 operating system
5.0 inch LTPS LCD screen with a resolution of 1024x768
Capacitive screen, multi-touch, operable even if hands in wet satus or wearing gloves
Omnidirectional and automatic identification of linear barcode or 2-dimensional barcode
Support reading and writing RFID (UHF) with 920-928 MHz and 865-868 MHz frequency, reading distance is 0-150 cm;
Support Protocol: EPC Global UHF Class 1 Gen 2/ISO 18000-6C/ ISO 18000-6B etc.
Support reading and writing RFID (HF / NFC) with 13.56 MHz frequency;
Support Protocol: ISO14443A, ISO1443B and ISO15693 etc.
Support scanning barcode and reading RFID simultaneously
Support comparison between scanning data and reading RFID data
With GPS positioning function
IP67 dust-proof, waterproof
Support 1.2 meters free fall and 200 times 0.5 meters roll off
Intelligent Mobile Terminal BV7237S UHF
Performance
Operating System: Android 6.0
CPU: 4-core 1.45 GHz high-performance processor
Internal Memory: 32GB ROM + 3GB RAM
Scalability: support for SDHC micro SD slot (expandable to 32GB)
SIM Card Slot: dual SIM card, NAno + micro
Working Battery: Rechargeable 3.8V 4300 mAh lithium polymer safe battery, support fast charging
Working Hours: 10 hours (full load work)
Prompt Way: sound / vibration / LED light
Support Interface: micro USB, support USB2.0 OTG
Wireless Communication
Network Standard/ Frequency Range: GSM/EDGE(2G) Band 2/3/5/8；WCDMA（Unicom 3G）Band 1/2/5/8;
TD-SCDMA（Mobile 3G）Band 34/39；TD-LTE（Mobile 4G）Band 38/39/40/41； LTE-FDD（Mobile / Telecom / Unicom）Band 1/3/7/20；GSM/GPRS/EDGE/WCDMA/HSDPA/HSUPA/HSPA+；GSM/GPRS/EDGE: 850/900/1800/1900；UMTS/HSDPA/HSUPA: 850/900/1900/2100
Wireless LAN (WLAN): WIFI 802.11 a/b/g/n Support 2.4G and 5G frequency range
WLAN Security Protocol: WPA(PSK), WPA2(PSK), WEP, TKIP, AES, EAP (MD5 CHAP, MS CHAP V2, TLS, PEAP)
Bluetooth: Bluetooth 4.0
GPS: Support GPS/AGPS
Data Engine
Barcode Scanning:
Automatically identify one-dimensional laser or two-dimensional image, and with sound and vibration reminder, reading instruction function.
Barcode Scanning: Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, China post 25, ISBN/ISSN, Code93, UCC/EAN-128, GS1 Databar, HIBC, etc.
QR code scanning, identification code system: QR, PDF417 Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codebar, Interleaved 2 of 5, China post 25, ISBN/ISSN, Code93, UCC/EAN-128, etc.
Scanning Angle: Omnidirectional
RFID UHF ( Reading / Writing):
Support Protocol: EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
Working Frequency: 902Mhz–928Mhz 865MHz–868MHz
Output Power: 18 ~ 26 dBm
Quick Start: <80 ms
Peak Speed: >50 sheets/s
UHF Antenna: Ceramic antenna
Reading Distance: 0 ~ 1.5 meters (test tag: Impinj E41b)
Supported Area: China (Other region is optional)
RFID ( Reading / Writing):
Reading and Writing RFID (HF/NFC) with13.56 MHz frequency;
Support Protocol: ISO14443A, ISO1443B and ISO15693
Physical Characteristics
Camera: Front camera with 13 million pixels, rear camera with 13 million pixels flash and auto focus
Display: 5-inch HD, 1024 * 768, penetrating IPS LCD, support using in dark environments
Touch Panel: capacitive touch, 5 point touch, fit completely, support for finger or latex gloves touch
Interactive Sensors: infrared sensor, light distance sensor, gravity sensor, compass sensor
Fingerprint Identification: Supports fingerprint capture for different applications, such as unlocking, authentication, and payment
Keyboard:
6 side buttons: left and right exclusive scan button, power button and lock screen, volume control button, camera button
3 main keys: Home key; Back key; Scan key
Sound: speaker, dual MIC noise canceling microphone
FM: Support FM radio
Multimedia: Support audio formats: AAC, AAC +, AMR-NB, MIDI, MP3, WMA
Video decoder (player): MPEG4, H.263, H.264, VC-1
Charging Interface: 1, USB port charging
Dimensions (L * W * H): L162 * W77 * H24 mm
Weight: 305g
Operating environment
Operating Temperature: -20 °C to 50 °C / -4 °F to 122 °F
Operating Humidity: Operating humidity 10% to 90%, storage humidity 5% to 95% (non-condensing)
Protection Class: IP67
Drop Standard: Support 1.2 meters free fall and 200 times 0.5 meters roll off
Certification: RoHS, CCC
Peripherals and Accessories: battery, USB data cable, power adapter,
-
BAOBIWANXIANG
Leading provider of the Internet of Things industry in China,providing personnel and items identification technology, products and total solutions.It’s a high-tech enterprise integrating R&D, production, sales and technical services.Totally obtain 217 patents.
-
